Boiler Kits

Sealpro's selection of boiler kits cover the most commonly required for Cleaver-Brooks® boilers. We maintain an inventory of kits for the following boiler types (graphite kits are also available).

Other specialty kits are available on request.

CB - Fireside Boiler Kits

Diameter Horsepower Kit Number
36"  15-40 BK-213
48" (before 1969)  50-100  BK-214
48" (after 1969)   50-100 BK-215
60"  125-200 BK-216
78" 250-350 BK-217
96" 400-800 BK-218


CBLE - Fireside Boiler Kits

Diameter Horsepower Kit Number
60"  125-200 BK-782
78" 250-350 BK0-780
96" 400-800 BK-781

Fireside kits typically contain the following (depending on model): Tadpole gaskets, segmented gaskets, sized insulation, fiberglass tape and rope, fastener clips, rivets and spray adhesive.


CB - Fireside Boiler Kits

Diameter Horsepower Kit Number Contents
48"  50-100  BK-209 (7) 3-1/4" x 4-1/2" x 1/2" Topog-E® Handhole Gaskets*
(2) McDonnell Miller 150-14 Water Column Head Gaskets**
60"-96" 125-800  BK-212 (1) Topog-E® 11" x 15" x 1-1/4" Manway Gasket*
(6) 3-1/4" x 4-1/2" x 1/2" Topog-E® Handhole Gaskets*
(2) McDonnell Miller 150-14 Water Column Head Gaskets**
60"-96"   125-800 BK-212A (1) Topog-E® 12" x 16" x 1-1/4" Manway Gasket*
(6) 3-1/4" x 4-1/2" x 1/2" Topog-E® Handhole Gaskets*
(2) McDonnell Miller 150-14 Water Column Head Gaskets**

* Other gasket sizes & material types available on request.
** TFE can be substituted for non-asbestos for an additional charge.
